2.0 inch 128x64 graphic dot matrix LCD display module series HTM12864-23 series introduction

? Type: COG LCD module with board

? Display pixels: 128x64

? Dimensions (mm): 54.6x50.0x9.1

? VA window size (mm): 45.2x27.0

? AA size (mm): 40.93x24.29

? Pixel pitch (mm): 0.38x0.32

? Application: stage controller

? Viewing angle: 6H

? Pin: 16PIN

? Interface: MCU

? Operating temperature: -20~70℃

? Supply voltage: 3.3V

? Driver chip：ST7565

HTM12864-23 series graphic dot matrix module product description

This 2.0-inch LCD display module, with its carefully optimized design and excellent performance, is committed to providing unparalleled readability under various harsh lighting conditions. In strong ambient light, such as direct bright sunlight, this 2.0-inch 128x64 display module is transflective. It can cleverly reflect ambient light back to the viewer's eyes, significantly improving the brightness and recognition of the screen content, effectively solving the pain point of traditional transmissive LCDs that are difficult to see under strong light, ensuring that information transmission in outdoor places is still clear and accurate. When the environment turns dim or completely dark, the module's integrated powerful LED backlight system immediately shows its value. When turned on, the backlight can evenly illuminate the entire display area, providing an excellent high-contrast effect, allowing white information to stand out clearly from the deep black background, presenting users with glare-free, detailed visual content. This innovative display solution that combines reflective technology with powerful backlight ensures that the module can calmly cope with extremely variable lighting environments from the scorching sun at noon to the dark at night, achieving true "clear visibility all day long" and making information reading no longer subject to light conditions.

The module was designed with full consideration of seamless integration with mainstream development platforms, especially full compatibility with the Arduino ecosystem, providing standard SPI or I2C interfaces for easy and fast "plug and play" connection. Its universal design also ensures that it can be easily integrated into electronic systems based on various microcontrollers such as Raspberry Pi and STM32, greatly broadening the boundaries of its applicable scenarios.

By matching different polarizer modes and backlight compositions, different display effects can be presented.

2.0 inch 128×64 graphic dot matrix module/128x64 resolution/ST7565 control chip /MCU HTM12864-23-01Y-A3P

2.0-inch graphic dot matrix module/128x64 graphic LCD display module/ST7565 control chip/white background with gray characters   HTM12864-23-31W-A3P

2.0 inch 128x64 LCD graphic LCD module/128x64 graphic dot matrix module/MCU interface/3.3v  HTM12864-23-11W-A3P

2.0 inch LCD graphic module/128x64 dot matrix yellow-green graphic LCD/STN+/3.3v/MCU interface   HTM12864-23-11Y-A3P

For different modes and backlight matching effects, please click on the link: LED backlight and LCD color to learn more!

For the related 128x64 dot matrix graphic LCD series, we provide users with different sizes, please contact us for more product recommendations.
